Toro GrandStand 72509 23.5hp Kawasaki FX Engine 60″ FAB Deck Mower (Local Pickup Only)

Toro GrandStand 72509 23.5hp Kawasaki FX Engine 60″ FAB Deck Mower (Local Pickup Only)
Conserves space to get more machines on your trailer, or allows for a smaller trailer and lighter load.
Foldable operator platform instantly converts the machine to a walk-behind.
Great visibility for easy navigation around obstacles, protecting the operator, mower, and property.
Quick access to the engine, hydros and controls with the easy removal of the fuel tank.
No hydraulic hoses, reduced parts, no routine greasing and simplified design to save you time.
Self-adjusting suspension and a larger platform area for a more secure stance on sloped terrain.
The TURBO FORCE® cutting deck is built to withstand the long, tough days on the job.
10.5 gallon fuel tank for fewer fill-ups. Transparent tank make it easy to gauge the fuel level.
A wide stance and optimal balance enhance hillside stability and control.
Horizon360® Business Management Software. Work More Efficiently. Run More Profitably.
Specifications
Adjustable Discharge Baffle
Standard, Tools-Free
Air Filter
Heavy-Duty Canister Air Cleaner
Anti Scalp Wheels
Standard
Blade Tip Speed
18,500 ft/min / 5,638 m/min
Blades
0.204 in. (0.5 cm) heat-treated steel
Box Dimensions
90 in. x 70 in. x 52 in. / 228.6 cm x 117.8 cm x 132.1 cm
CARB Compliant
Not CARB Compliant
Carrier Frame
3 in. x 1.5 in. x 12 gauge (7.6 cm x 3.8 cm x 12 gauge)
Caster Tires
11 in. x 4 in. – 5 in. (27.9 cm x 10.2 cm – 12.7 cm) Flat-Free Semi-Pneumatic
Clutch
Electromagnetic
Comfort Platform
Foldable Operator Platform with Suspension
Controls
Twin lever
Deck Design
7-gauge 60″ (152.4 cm) TURBO FORCE® w/bull-nose bumper
Deck Material
7 Gauge Steel
Deck Size
60 in / 152 cm
Discharge Chute
Rubber
Drive System
Unitized Pumps 10cc rev Wheel Motors 10 cir
Drive Tires
20 in. x 10.5 in. – 8 in. (50.8 cm x 26.7 cm – 20.3 cm)
Engine
23.5 hp* Kawasaki FX730V 726 cc
Engine Brand
Kawasaki
Engine Displacement (cc)
726 cc
Engine Horsepower
23.5 hp
Forward Ground/Transport Speed
Up to 10.0 mph / 16.0 kph
Front Bumper
Reinforced Bull-Nose
Fuel Capacity
10.5 gal. / 39.7 L / 42 Qt.
Fuel Type
Gasoline
Height of Cut
1.5 – 5.0 in. / 3.8 – 12.7 cm
Hour Meter
Standard
Hydraulic Fluid
Premium synthetic
Product Type
Stand-On Mowers
Product Use
Commercial
Spindle Bearings
Maintenance-free
Spindle Housing
9 in / 22.9 cm Diameter Cast Aluminum
Start Type
Electric
Steering Controls
Twin Lever
Weight
960 lbs / 435.4 kg
Disclaimer
*23.5 HP gross at 3,600 RPM SAE J1940 and SAE J2723, as rated by Kawasaki®. As configured to meet safety, emission and operating requirements, the actual engine horsepower on this mower may be significantly lower.
